Look a little closer
See the mechanism
A loop passes around the bobbin assembly
Read the diagram steps
Bottom of stroke. The needle carries upper thread through the fabric. The feed dog is below the plate, returning for the next feed.
Needle begins rising. Fabric resists the thread following the rising needle, opening a loop on its scarf side. The hook point enters this loop; the take-up is supplying thread.
Loop carried around. The rotating hook spreads the upper loop around the restrained basket and bobbin assembly, placing bobbin thread through the loop. The take-up remains low to supply the needed length.
Tighten and feed. After the loop clears the hook assembly, the rising take-up retrieves extra upper thread and sets the interlacing near the fabric. Feed teeth above the plate advance the fabric while the needle is out.
Thread topology and motions enlarged in a functional rotary-hook/drop-feed section. The basket is restrained while the outer hook rotates. Thread colors identify separate supplies, not a cutaway of one exact machine; timing angles and service settings omitted.
Diagram basis: Union Special, Lockstitch Formation Type 301, pp. 4–15.
Sources: Union Special Corporation; scan hosted by Szwalnicze
The loop forms as the needle starts back up
The needle has an eye near its point, so it carries thread through the fabric on its downward stroke. After reaching the bottom, it starts upward while the material resists the thread following immediately. A loop forms on the needle's scarf side, where the hook can reach it.
The loop is temporary working space. It has to open enough for the hook point to enter, then grow enough to pass around the bobbin assembly. Needle motion, hook motion and available upper thread therefore have to occur in the right sequence.
Sources: Union Special Corporation; scan hosted by Szwalnicze
The hook carries the upper loop around the lower thread
In the rotary-hook example, the hook rotates while the bobbin holder is restrained from rotating with it. The hook catches the needle-thread loop and spreads it around the bobbin assembly. This places the bobbin thread through the upper loop without sending the needle or an entire spool through the fabric.
The hook then releases the loop. The machine has made the crossing needed for the two threads to interlace, but the extra upper thread still has to be removed. Loop capture alone is not yet a tightened stitch.
Sources: Union Special Corporation; scan hosted by Szwalnicze
The take-up first gives thread, then retrieves it
The take-up moves down to make needle thread available while the hook enlarges the loop. Later it rises, drawing the surplus back out of the hook area. The interlacing point is pulled toward the fabric as the stitch tightens.
The two thread supplies meet in the seam, with needle thread on one side and bobbin thread on the other. Their tension affects where the interlacing sits. That is why a machine needs both a thread-delivery path and a loop-taking mechanism rather than only an up-and-down needle.
Sources: Union Special Corporation; scan hosted by Szwalnicze
The fabric advances between penetrations
In the plain drop-feed example, feed-dog teeth rise through the needle plate, carry the fabric along while the needle is out, then drop and return below the plate. The presser foot holds the fabric against this moving support.
Repeating the timed cycle places the next interlacing a little farther along the seam. The feed determines the separation between stitches; it doesn't create the thread crossing. Those two mechanisms cooperate to turn repeated local stitches into a continuous line.
Sources: Union Special Corporation; scan hosted by Szwalnicze
The thing to remember
The hook forms the interlacing, the take-up tightens it, and the feed moves the fabric for the next stitch.
What this example leaves out
This explains a single-needle lockstitch with rotary hook and plain drop feed. Oscillating hooks and other feed systems differ. The schematic omits exact timing angles and provides no threading, adjustment or repair procedure.
