Look a little closer
See the mechanism
The coating supplies the main reflection
Read the diagram
At a back-coated mirror, the main ray enters the glass, bends toward the surface normal, reflects at the rear coating and passes back out through the front. Its angles inside the glass obey reflection symmetry; refraction occurs at both front crossings. A weaker front-surface reflection follows a separate path.
Original ray construction. Layout uses an illustrative glass index of 1.5 and an oblique incident ray solely to enforce Snell geometry; neither is a measured property of a named mirror. Thickness is exaggerated. Line width is not brightness. Other mirrors use first-surface or nonmetal coatings.
Diagram basis: OpenStax: reflection and normals; Edmund Optics: second-surface mirrors and front reflection.
Sources: OpenStax, Rice University · Pilkington / NSG · Edmund Optics
A clear image needs an orderly reflection
A smooth surface sends an incoming ray into a predictable direction. The angle of reflection equals the angle of incidence, measured from the normal: an imaginary line perpendicular to the surface. That rule applies locally; it doesn't say every incoming ray returns toward its source.
A rough surface has many differently oriented patches, which send light in different directions. It can reflect light without presenting the sharp image associated with a flat mirror. Reflecting light and preserving an image are related but different requirements.
Sources: OpenStax, Rice University
The main reflection happens at the coating
Pilkington's Optimirror range uses a protected reflective silver layer on glass. In the back-coated arrangement, the glass supports and shields the reflective surface. The ray travels through that transparent thickness before and after its main reflection. Transparent glass carries light to the reflective layer rather than supplying the main mirror image.
Edmund Optics distinguishes this second-surface geometry from a first-surface optical mirror, whose reflective coating faces the incoming light directly. Silver is one coating choice; aluminum and other optical constructions also exist. A mirror is not defined by one universal metal or layer thickness.
Sources: Pilkington / NSG · Edmund Optics
The front of the glass can make a faint second path
Some light reflects at the glass's front surface instead of reaching the metal. In a second-surface mirror, that weaker path can produce a faint extra reflection alongside the main one. The two reflections begin at different depths, so their paths can emerge displaced from one another.
A first-surface mirror places the main coating at the first surface. Light reaches that coating directly, avoiding the extra trip through a glass substrate before and after reflection.
Sources: Edmund Optics
The thing to remember
The metal coating supplies the main reflection in a typical glass mirror. Its smoothness preserves image directions, while the front glass can add a faint reflection.
What this example leaves out
This selects a flat back-coated glass mirror. Front-surface, curved and multilayer optical mirrors differ. The ray sketch does not specify reflectance, coating lifetime or an exact product layer stack.
