Look a little closer
See the mechanism
The sensing element is an elastic spring
Read every step
- Unloaded beam. A strain gauge is bonded to an elastic sensing element. Before the illustrated load, the beam has its reference shape. The gauge follows the surface rather than measuring mass directly.
- Load bends the element. An applied force bends the elastic element. The bonded gauge strains with that surface and its electrical resistance changes. Measurement electronics turn the calibrated sensor signal into a displayed result; this drawing assigns no made-up reading.
Original bending-beam principle, not a cutaway or sensor count for every domestic scale. The gauge pattern and deformation are enlarged; one visible gauge stands in for a complete instrumented element. No invented kilogram display, sensitivity, wiring bridge or tare algorithm is shown.
Diagram basis: HBM/HBK: elastic element and bonded strain gauges.
The platform passes the force into a sensing element
The part you place an object on isn't the whole sensor. A scale's structure transmits the load to one or more load cells. In the strain-gauge arrangement here, each load cell has an elastic body designed to deform slightly under that force.
The small deformation stretches and compresses local regions where the strain gauges are attached. The visible platform doesn't need to sag noticeably for a useful signal to appear.
The gauges follow that deformation
A bonded strain gauge deforms with the part beneath it. Its fine electrical conductor becomes longer under tension and shorter under compression, changing its resistance. The sensing chain is therefore force, elastic deformation, then resistance change in the gauge. The electronics aren't measuring the resistance of the entire weighing platform.
HBM describes wiring gauges into a Wheatstone bridge. That circuit turns their small resistance changes into a measurable voltage. An amplifier and the following electronics can process this signal instead of trying to read a tiny mechanical displacement from a pointer.
The display needs a relationship between signal and load
A voltage on its own isn't yet a weight reading. Calibration establishes how the load cell's electrical output corresponds to applied loads. The scale can then turn a measured signal into the units on its display.
That relationship assumes the intended load path and operating range. Sideways forces or a different mechanical arrangement can affect a load cell. The mounting must carry the intended load through the sensing element for that calibration to remain useful.
The thing to remember
The number begins with a controlled elastic deformation. Strain gauges turn that movement into resistance changes, and calibration connects the signal to a load.
What this example leaves out
This follows a strain-gauge load-cell scale with a simplified elastic element. It doesn't specify the number or exact mounting of sensors in every household scale, and it isn't a wiring, calibration or repair procedure.
