Seal to compress; bypass to refill
Read every step
- Refill stroke. As the piston rises, the peripheral O-ring shifts away from its tapered sealing seat. Incoming air can pass through the bypass grooves around the piston into the enlarging chamber below. The outlet check ball stays seated, preventing delivery air from returning.
- Compression stroke. As the piston descends, the O-ring seats against the taper and cylinder wall, closing the bypass. Chamber pressure rises. Once it exceeds downstream pressure, the outlet ball lifts and air passes through the piston’s delivery passage toward the hose.
Original functional first-embodiment map based on US5127804A, not the internals of every floor pump. O-ring, taper, bypass and ball check are enlarged and simplified. Delivery follows the through-piston passage. Tire-valve construction, seat-post mounting and pressure ratings are omitted.
Diagram basis: US5127804A: compression/refill passages around Figs. 3–4.
Moving the piston back makes room for fresh air
The cylinder contains a piston with a sealing arrangement. As the piston moves away from the closed end, the working chamber grows. An intake route admits air so the chamber can refill for the next delivery stroke.
One documented bicycle-pump design, US5127804A, combines the intake action with an elastic ring at the piston. The ring can allow a refill route in one direction and seal it in the other. The exact route differs between pumps; it doesn't require a permanently open hole that would also leak during compression.
A sealed, shrinking chamber raises the pressure
On the delivery stroke, the piston moves toward the closed end and the intake route seals. Air is compressed into a smaller volume. At first, the outlet valve can remain shut: the chamber hasn't yet reached the pressure needed to send air onward.
In the selected patent, a separate outlet check valve opens when the chamber pressure rises above that in the outlet passage. Air can then enter that passage and continue through the pump's delivery connection. Pushing the handle provides the work; the valve determines which direction that pressure can drive the flow.
Refilling the pump shouldn't empty its outlet
When the piston reverses, chamber pressure falls. The outlet check valve closes against reverse flow while the intake route admits new air. The pump can therefore repeat the cycle instead of drawing the same air backward and forward through one open connection.
The tire has its own valve at the other end of the delivery route. That is a separate component from the pump's check valve, even if both restrict reverse flow. The pump's valve keeps delivered air out of the refilling chamber; the tire valve controls the connection at the tire.
The thing to remember
The piston compresses a fresh charge of air. The intake and outlet valve actions make that repeated motion deliver air in one direction.
What this example leaves out
The selected source is a seat-tube bicycle-pump design, used here for a simplified single-action piston/check-valve principle. The drawing isn't a floor-pump SKU cutaway, and it doesn't assign the same intake path or tire-valve mechanism to every pump.
