A finger changes coupling at grid crossings
Read the diagram steps
Untouched crossing. A controller drives a transmitter electrode and reads its capacitive coupling to a receiver electrode. Repeating this across the grid establishes a reference pattern.
Finger nearby. A conductive finger couples to the electric field near a crossing, changing the mutual-capacitance signal reaching the receiver. The controller compares crossings to locate the touch; pressure is not the measured input.
Functional mutual-capacitance cross-section, not an electric-field simulation. Curved lines show coupling routes qualitatively, not measured field strength. Electrode geometry and signal processing differ among screens.
Diagram basis: Microchip Capacitive Touch Sensor Design Guide, pp. 24–25.
Sources: Microchip Technology · Microchip Technology
The glass covers a measuring grid
The sensing layer contains conductors arranged as transmit and receive electrodes. Each nearby pair forms a small capacitance: a relationship between applied voltage and stored electrical charge. The controller drives a transmit electrode and measures the response at receive electrodes.
The sensing electrodes and the display pixels have different jobs. Pixels make the picture. The touch grid supplies measurements from which electronics can locate a finger over that picture. The cover can insulate your skin from the conductors while the electric field extends through it.
Sources: Microchip Technology
A finger changes the field, not just the load on the glass
Your finger is conductive and electrically coupled to the rest of your body and its surroundings. Near an electrode pair, it changes the field that links the transmitter and receiver. Microchip's model separates two effects: the finger can add coupling between the electrodes, but it also provides an additional capacitive return path that reduces charge transferred to the receiver.
In the usual mutual-capacitance touch response, that reduction dominates. The controller sees a change relative to its untouched baseline. The simplified drawing therefore shows less direct coupling near the finger, not a glass plate bending to close an electrical contact.
Sources: Microchip Technology
Several measurements describe one fingertip
A finger covers an area rather than a mathematical point. Measurements across nearby sensing locations form a patch of changed values. A touchscreen controller can use that distribution to calculate a position and follow it as the finger moves.
The signal depends on the sensor layout, cover and electrical coupling. A thick insulating layer can weaken the change reaching the sensor. This is why pushing harder is not the basic measuring principle, and why glove support depends on the device and glove rather than on one rule for every capacitive screen.
Sources: Microchip Technology · Microchip Technology
The thing to remember
The reported point is a calculation from electrical changes across a grid. The fingertip changes how that grid couples charge.
What this example leaves out
This describes mutual-capacitance sensing. Devices can combine sensing modes and use different electrode patterns, filtering and glove or moisture handling. The schematic is a field model, not an exact phone layer stack.
